AUTOLISP: the Construction of the axes of the circle


The program is designed to build axes of circles or arcs in RUSSIAN versions of autocad 2013 ... 2017 and later.
The program asks you to specify a circle or arc.
As a result, the axes of the selected objects are plotted.

Additional information

Center1234 file.place the lsp with the program in a separate folder after the purchase, for example E:\LSP.
Go to the menu (Tools Настройка settingsFilesTrusted locations ) and add the path to this folder E:\LSP. Then go to the menu
(Service Aut AutuLispApplications) and in the autoload group, click the APPLICATIONS button and add the center1234 file there.lsp for automatic loading.
To assign a separate button
go to Tools _ Customize _ Interface and click the "Create a new command" button. Enter the name of the command and its description, such as "circle Axes".
Enter the name of the _ center1234 function in the macro line.
The new "circle Axes" command should appear in the list at the bottom left.
Drag it with the right mouse button to the desired panel in the "tree" of the neighboring window at the top and click OK.
