Decisions Control K3 Figure 2 conv 8 (version 28) 89 Targ Decisions Control K3 Figure 2 conv 8 (version 28) 89 Targ


Cразу после оплаты Вы получите ссылку на архив с решением задачи по теоретической механике К3 В28 (рисунок 2 условие 8) из методички Тарг С.М. 1989 года для студентов-заочников машиностроительных, строительных, транспортных, приборостроительных специальностей высших учебных заведений. Задача выполнена в формате word, запакована в архив zip.

Additional information

Solution of the Task R3 Option 28: Flat mechanism consists of rods 1, 2, 3, 4 and slider B or E (Fig. KZ.0 - K3.7) or bars 1, 2, 3 and slider B and E (Figure . K3.8, K3.9), connected with each other and with fixed bearings O1, O2 hinges; the point D is in the middle of the rod AB. The lengths of the bars are, respectively, l1 = 0,4 m, l1 = 1,2 m, l3 = 1,4 m, l4 = 0,6 m. The position of the mechanism is determined by the angles α, β, γ, φ, θ. The values \u200b\u200bof these angles and other predetermined values \u200b\u200bare listed in Table. ACA (for Figs. 0-4) or in the Table. HSC (for Fig. 5-9); while Table. ACA ω1 and ω4 - constant. Determine the values \u200b\u200bshown in the tables in the columns of "Find." Arc arrows in the figures show how the construction drawing of the mechanism should be postponed corresponding angles: in the course of, or counter-clockwise (for example, the angle γ in Fig. 8 should be deferred from the DB in a clockwise direction, and Fig. 9 - counter-clockwise arrows, and so on. d.). Construction to begin drawing the rod, the direction of which is determined by the angle α; slide with runners for greater clarity to portray as in the example of RS (see. Fig. HSC). Given angular velocity and angular acceleration considered a counterclockwise direction, and set the speed and acceleration vB ab - from B to b (Fig. 5-9).
