Drain tap MCH00.03.00.00 solidworks
Uploaded: 26.01.2022
Content: 03.rar 1286,28 kB
Product description
Drain tap MCH00.03.00.00 3d model
Drain tap MCH00.03.00.00 3d solidworks
A drain cock is mounted at the end of the pipeline and serves to drain the liquid. When draining, the handle pos.4 is installed along the pipeline, to stop the drain - across. To ensure tightness, the cork cone pos. 2 is lapped against the inner wall of the housing pos.1.
Cover pos.3 and bushing pos.5 provide the necessary tightness of the plug pos.2 to the inner surface of the body pos.1
3D model (shown in screenshots) made by SOLIDWORKS 2016.
It is also possible to open and view 3D models made in SOLIDWORKS in the SolidWorks eDrawings Viewer.
Please write to L/S for all questions. I will answer and help.
