Apparatus A 433 includes M-propelled trolley 3, which is mounted on the welding
9 head with current lead 2, the hopper 6 to the flux and the control panel 7.
The running gear 5 trolleys and wire feeder are driven by separate motors. Wire feed speed - constant.
Pre-setting the feed rate changes the gears feeder.

The machine moves on the light rail track 8 having rack.
The rail can be tough (for welding longitudinal seams) or flexible
(Welding curved joints) and is installed parallel to the seam pattern.
When using a flexible rail radius of curvature, which must match the curvature of the joint can not be less than 3 m.
The welding head 9 together with the mouthpiece 2 (current supply) mounted on a support 10 twin,
with which you can move the head in two mutually perpendicular directions in gorizontalnoyploskosti and adjust the position of the electrode across the seam and along the gap. Welding 1 bath is kept front and rear sliders 11, water-cooled, which linked the knife 4,
passing through the gap between the edges and the spring system. The running machine has a device
allows you to disable the gear unit from the carriage and manually move the march to move the carriage along the rail.

Technical specifications
Core wire diameter, 3 mm
Wire feed speed, m / min 1.1 - 1.7
welding speed, m / h 2.6 - 21
Rated welding current at CR = 100%, 1000
Adjusting welding current A 120 - 1000
Power supply trehfaznon network, 380 or 220
Weight of the electrode wire in the coil 10 kg
Hopper capacity for flux 10 dm3
Overall dimensions of the machine (without rail), mm
- Length 392
- Width 440
- Height 800
The weight. 40 kg
Overall dimensions of the cabinet, Power Management. mm
length 900
width 530
height 750
The weight. 110 kg
