Video surveillance project on SKAT-v.8

A CCTV (video surveillance) system design in AutoCAD (DWG) for a large office center.

The CCTV system (CCTV) is based on imported equipment.
The CCTV system is based on a personal computer with an integrated AceCop video surveillance card (SolarCop 16100B digital recorder), which is installed in the security office. Two redundant, eight-channel secondary power supplies (SKAT-v.8) are also installed there to power the video cameras. Outdoor black-and-white video cameras are mounted on the building walls at a height of at least 2.5 meters above the ground to monitor the building´s perimeter, approaches, and windows.
