Targ S.M. 1988 C1 option 72
Reviews 0
Secure deal
Instant delivery
Product description
The rigid frame is fixed at the point A by a hinge, and at the point B it is attached either to the weightless rod BB₁, or to the hinged support on the rollers; the rod is attached to the frame and to the fixed support by the hinges. A pair of forces act on the frame with the moment M = 100N · m and two forces. Determine the reaction of bonds at points A and B. In the final calculations take l = 0.5 m.
Given: H: α₂ = 45⁰; F₂ = 20H; K: α₃ = 30⁰; F₃ = 30H.
Given: H: α₂ = 45⁰; F₂ = 20H; K: α₃ = 30⁰; F₃ = 30H.
Main features
- Content type File
- Content description 30,63 kB
- Added to the site 26.05.2024
Additional information
Thank you for your purchase. If you have questions write to the mail. See "Seller Information"
