Targ S.M. 1988 C2 option 08

Affiliates: 0,02 $how to earn
Pay with:
i agree with "Terms for Customers"
Sold: 0
Uploaded: 22.01.2019
Content: C2_08_88.pdf 51,26 kB
Loyalty discount! If the total amount of your purchases from the seller Timur_ed more than:
15 $the discount is20%
If you want to know your discount rate, please provide your email:

Product description

Homogeneous rectangular plate weighing P = 5kN with sides AB = 3L; BC = 2L; it is fixed at point A by a spherical hinge, and at point B by a cylindrical hinge (bearing) and held in balance by a weightless rod CC ´. A pair of forces with a moment kNm, lying in the plane of the plate, and two forces act on the slab. Determine the reaction of bonds at points A, B and C. When calculating, take L = 0.8 m.
Given: D: F₃ = 8kN; α₃ = 0 ° E: F₄ = 10kN; α₄ = 60 °.

Additional information

Thank you for your purchase
