Targ S.M. 1988 C2 option 50
Refunds: 0
Uploaded: 11.03.2022
Content: C2_50_88_idz-student.kz_.pdf 39,62 kB
15 $ | the discount is | 20% |
Product description
Fig.5 usd.0
Homogeneous rectangular plate weighing P = 5kN with sides AB = 3L; BC = 2L; fixed at point A by a spherical hinge, and at point B by a cylindrical hinge (bearing) and held in balance by a weightless rod CC ´. A pair of forces with a moment M=6kNm, lying in the plane of the plate, and two forces act on the slab. Determine the reaction of bonds at points A, B and C. When calculating, take L = 0.8 m.
Given: E: F₁ = 4kN; α₁ = 60 °; H: F₃ = 8kN; α₃ = 0 °.
