Targ S.M. 1989 C2 option 77
Reviews 0
Secure deal
Instant delivery
Product description
The structure consists of a rigid angle and a rod, which at point C are either hinged to each other or freely resting on each other. The structure is acted upon by: a pair of forces with a moment M=60 kNm, a uniformly distributed load with intensity q=20 kN/m and two forces. Determine the bond reactions at points A, B, C. For final calculations, take a=0.2m.
Given: H:F₂= 20kN; α₂= 60⁰; L: F₃ = 30kN; α₃ = 30⁰; CK.
Given: H:F₂= 20kN; α₂= 60⁰; L: F₃ = 30kN; α₃ = 30⁰; CK.
Main features
- Content type File
- Content description 55,87 kB
- Added to the site 02.02.2025
